Powering Riyadh Metro with reliable energy infrastructure
Powering Riyadh Metro with reliable energy infrastructure
Supplying, manufacturing and providing support for LV panels, Package substations, and MV/LV cables across Riyadh Metro lines.
0lines
Metro Network
Three lines and 62 Passenger Stations (BACS & ANM) of Riyadh Metro.
0km
System length
Underground, elevated shallow and Iconic stations
0% acceptance
Client approval
Final configurations approved with full documentation
Riyadh Metro is one of the region’s most ambitious mobility programs, representing a total investment of 22 billion dollars, built to ease congestion and improve access across the capital.

The six-line, 176 km network requires power systems that run reliably in tunnels, stations, depots and control facilities.

alfanar was selected to manufacture and supply low-voltage panels, package substations and MV/LV cables, engineered for safe distribution in a multi-contract environment with strict standards and complex interfaces.

Keeping production moving amid shifting designs

As the project follows a fast-track design-and-build approach, production and drawing issuance progressed in parallel with ongoing design revisions, requiring continuous coordination to align with the latest updates.


Frequent revisions risked material waste, factory downtime, and missed FAT slots. Deliveries still had to align with site needs and meet ADA, SEC and IEC requirements, with zero tolerance for lapses during energisation and testing.

Modular manufacturing with live design control

A dedicated design interface team tracked SLD changes and pushed approved updates straight into manufacturing drawings. Modular build processes let factories adapt with minimal scrap. A clear technical clarification flow resolved ambiguities with EPCs before fabrication.

QA/QC, planning and engineering re-sequenced FAT in parallel with drawing updates, while digital document control kept current BOMs and drawings visible to every department.


Local manufacturing shortened lead times; site teams coordinated delivery, SAT and handover with training and technical support.

https://devalfwebstr.blob.core.windows.net/dev-container/Newsroom/CaseStudies/RiyadhMetro/RiyadhMetroLine.jpg
https://devalfwebstr.blob.core.windows.net/dev-container/Newsroom/CaseStudies/RiyadhMetro/KAFDMetroLine.jpg
https://devalfwebstr.blob.core.windows.net/dev-container/Newsroom/CaseStudies/RiyadhMetro/RiyadhMetro7.jpg
https://devalfwebstr.blob.core.windows.net/dev-container/Newsroom/CaseStudies/RiyadhMetro/RiyadhMetro4.jpg
Factory agility, field certainty
FocusAreasWithIconDesign change control
FocusAreasWithIconModular build + FAT
FocusAreasWithIconLocal delivery & support

PRODUCTS BEING USED

Low-voltage Switchgears
Low-voltage Switchgears
Factory-built LV switchboards for stations, depots and auxiliaries
Package substations
Package substations
Automatic Transfer Swritch panel, Power Factor Corrections panel, Motor Control Center and Variable Frequency Driver panel
MV/LV cables
MV/LV cables
Power and control cables across lines, stations and depots
Fire-rated LSZH cables
Fire-rated LSZH cables
Specified for tunnels and stations to meet global safety standards
Accepted, documented and ready for reliable operation

Accepted, documented and ready for reliable operation

alfanar supplied and commissioned LV panels, package substations and MV/LV cables across multiple lines.


Production continuity was maintained despite ongoing SLD revisions. All equipment complied with final approved drawings and standards and was verified through FAT and SAT.


The program achieved full client acceptance with complete traceability, reinforcing delivery capability in complex, multi-EPC environments.
